NTT-22 NMEA Tokimec Gyro Converter

NMEA Tokimec gyro converter is used to NMEA heading information to Tokimec gyro format. It also converts Tokimec gyro format to NMEA heading information. In this way, the installed devices are not affected by the retrofit. Operating modes can be set by jumper settings.

NMEA Tokimec gyro converter accepts HDT, ROT, THS telegrams to convert signal to Tokimec data. Default input speed is 4800bps, output speed is 9600bps. Different input-output speed options can be adjusted with DIP switches on the board.

The NTT-22 can be powered within the range of 9~32 VDC. The nominal voltage of 24 VDC is advised for powering the device in normal operation. Power input port has a protection for incorrect polarity connection of the supplying voltage.
