NTY-22 NMEA Yokogawa Gyro Converter

NMEA Yokogawa Gyro Converter is used to NMEA heading information to Yokogawa gyro format. It also converts Yokogawa gyro format to NMEA heading information. In this way, the installed devices are not affected by the retrofit. Operating modes can be set by jumper settings.

NMEA Yokogawa gyro converter accepts HDT, ROT, THS telegrams to convert signal to Yokogawa data. Default input speed is 4800bps, output speed is 9600bps. Different input-output speed options can be adjusted with DIP switches on the board.

The NTY-22 can be powered within the range of 9~32 VDC. The nominal voltage of 24 VDC is advised for powering the device in normal operation. Power input port has a protection for incorrect polarity connection of the supplying voltage.
